Power supply voltage

DC5-----28V

DC5V

With reverse polarity protection   function

Resolution

0.005……0.1mm

0.001…….0.1

Optional

System accuracy

±(0.05+0.02*L)mm

±(0.01+0.02*L)mm

Unit :m

Applied   magnetic ruler

5mm+5mm

2mm+2mm

Read head and the tape space

0.8mm----2.5mm

0.5------2mm

Power   consumption

                            <50mA

Under no load

Output driver current

Max+50mA line

Over current thermal protection

Output   mode (ABZ square ware signal)

PP push-pull / RS422   line driver

Optional

Cable length

  2m---------30m

Optional

Measuring   output speed

100KHZ

Protection rating

IP67

Working   temperature

-10℃……..+55℃

Storage temperature

-25℃……..+75℃

Shell

Black die   – cast aluminum
