YIHAO YH800-2K mini LCD DRO

YH800-2K mini LCD DROs, the brand-new small size LCD DRO on the market.

• Languages available in English, German, Polish, Hungarian, Russian, Ukrainian, Simplified Chinese, Traditional Chinese, Thai, Italian, Portuguese,Greek…; More to come!
• 3.5 inches true color LCD display.
• Preposition displaying reminding.
• Built-in type operation manual.
• Strong Anti-interference ability.
• Covered by a 2-year warranty.

This is a digital readout console only, if you need linear encoders for it, please check our product categories.

BOTH OUR GLASS SCALE AND MAGNETIC SCALE ARE COMPATIBLE WITH OUR DROs.

Please email us for the YIHAO YH800-2K mini LCD DRO user manual! if you would like to read it before placing your order.

• Mini digital readout A10 by YIHAO is available on 1 axis,2 axis,3 axis.
• Multiple background colors
• Languages available in English, German, Polish, Hungarian, Russian, Ukrainian, Simplified Chinese, Traditional Chinese, Thai, Italian, Portuguese, Greek…; More to come!
• Power Dissipation: 15W
• Voltage Range: AC80V-260V / 50HZ-60HZ
• Operating Keypad: Mechanical Keypad
• Input Signal:5V TTL or 5V RS422
• Input Frequency: ≤4MHZ
• Resolution Supported For Linear Encoder: 0.1μm、0.2μm、0.5μm、1μm、2μm、2.5μm、5μm、10μm
• Resolution Supported For Rotary Encoder: ＜1000000 PPR

YIHAO Mini digital readout YH800-2K FUNCTIONS:

• Zeroing, Data Recovery
• Preset value
• Metric and Imperial switch
• Power-off memory
• Encoder selection(Linear or Rotary)
• Linear Compensation & Non-linear compensation
• Counting Direction Setting
• ABS/INC Coordinate
• 100 sets of SDM Coordinates
• REF function
• Centering / 1/2
• PLD
• PCD
• Radius and Diameter Conversion
• Axis Summing
• Taper Measuring
• Linear Measuring Basing Rotary Encoder
• EDM Function (Optional, Pre-Order only)
• RS232 Interface (Optional, Pre-Order only)
• Rotation Speed Measuring (Optional, Pre-Order only)

WHY YIHAO?

We have a strong technical innovation and developing team supported by a group of well-experienced software and hardware engineers, all of our production staff possess years of experience in this field. This makes us continually provide always techniques advanced, durable products, and reliable solutions to our partners.
Currently, our company builds a thorough system of techniques innovation, parts supply chain, manufacturing, service, and quality control. We will always adhere to our company philosophy-basing on innovation, focusing on details, delivering reliability, servicing the clients.
We are not only the manufacturer of digital readout and linear scale systems but also a technology innovation-driven company including developing, designing, manufacturing and service together.

WHY YH800-2K mini LCD DRO?

If you run a mini lathe, mini drilling milling machine you will face pain while selecting a proper position readout, because the normal DROs are way too Big, and it is so hard to you to install a linear encoder, A10 mini LCD DRO however is just the right mini digital readout that solves your problem, YH800-2K simply wins customers’ good feedback from all over the world, as it gives convenience to machining, it is more readable than traditional LED DROs, it is very good while operating in the dark environment, and it can also be enabled to dark mode to protect machinist’s eyes.
